Isuzu Industrial Diesel Engines from 0.6L to 15.7 L
Isuzu is a representative commercial vehicle producer of Japan and is known for its reliability and track record of success. In addition to developing industrial diesel engines that include Isuzu’s own state-of-the-art technology and have powerful moving capabilities, Isuzu is continuously charging ahead in pursuit of reliability, durability, and eco-friendliness. Isuzu offers a wide-ranging line-up of low- and high-displacement engines. Isuzu will bring reliability to the world as the global standard for future generations.
2019 will see the introduction of EU Stage 5 engines into this market, Isuzu is ready for the challenge of the new regulations, with its high pressure common rail diesel engines with DPF filters.
Isuzu has a complete range of Industrial Diesel engines, listed below in the following chart, which also includes leaflets and 2D power pack drawings.
| Engine Model | Power Rating | Emissions Status | Leaflet | 2D Drawing |
| 2CA1 | 10.5 kW @ 3600 r/min | EU Stage 5 | Sales leaflet - 2CA1 | 2D Power Pack Drawing |
| 3CA1 | 17.0 kw @ 3600 r/min | EU Stage 5 | Sales leaflet - 3CA1 | 2D Power Pack Drawing |
| 3CJ1 | 15.1 kW @ 3000 r/min | EU Stage 5 | Sales leaflet - 3CJ1 | |
| 3CH1 | 17.8 kW @ 3000 r/min | EU Stage 5 | Sales leaflet - 3CH1 | |
| 3CE1 | G drive | EU Stage 5 | ||
| 4LE2X | 47.4 kW @ 2400 r/min | EU Stage 5 | Sales leaflet - 4LE2X | 2D Power Pack Drawing |
| 4JJ1X | 86.0 kW @ 2200 r/min | EU Stage 5 | Sales leaflet - 4JJ1X | Please contact Engines Plus Sales team |
| 4HK1 | 140.0 kW @ 2000 r/min | EU Stage 5 | Sales leaflet - 4HK1 | Please contact Engines Plus Sales team |
| 6HK1 | 210.0 kW @ 2000 r/min | EU Stage 5 | Sales leaflet - 6HK1 | Please contact Engines Plus Sales team |
| 6UZ1 | 270.0 kW @ 2000 r/min | EU Stage 5 | Sales leaflet - 6UZ1 | Please contact Engines Plus Sales team |
| 6WG1 | 382.0 kW @ 1800 r/min | EU Stage 5 | Sales leaflet - 6WG1 | Please contact Engines Plus Sales team |
Isuzu can also offer both emission compliant or non-emission compliant engines depending on the territory of destination, and for our “Lesser Regulated Engines” we have the following products
| Engine Model | Power Rating | Emissions Status | Leaflet |
| 3CB1 | 19.9 kW @ 3000 r/min | EU Stage 3a | Sales leaflet - 3CB1 |
| 3CE1 | 28.2 kW @ 3000 r/min | EU Stage 3a | Sales leaflet - 3CE1 |
| 4LE1 | 36.9 kW @ 3000 r/min | EU Stage 3a | Sales leaflet - 4LE1 |
| 4LE2T | 36.9 kW @ 2600 r/min | EPA Tier 4 Final | Sales leaflet - 4LE2T |
| 4LE2X | 47.4 kW @ 2400 r/min | EU Stage 3b / EPA Tier 4 Final | Sales leaflet - 4LE2X |
| 4JG1 | 46.3 kW @ 2600 r/min | EU Stage 2 | 4JG1 Leaflet |
| 4JJ1T | 52.0 kW @ 2000 r/min | EU Stage 3b / EPA Tier 4 Final | Sales leaflet - 4JJ1T |
| 4JG1T | 62.5 kW @ 2500 r/min | EU Stage 2 | 4JG1T Leaflet |
| 4BG1T | 91.7 kW @ 2500 r/min | EU Stage 2 | 4BG1T Leaflet |
| 4BG1TC | 96.4 kW @ 2200 r/min | EU Stage 2 | 4BG1TC Leaflet |
| 6BG1T | 121.6 kW @ 2200 r/min | EU Stage 2 | 6BG1T Leaflet |
| 6BG1TC | 132.3 kW @ 2200 r/min | EU Stage 2 | 6BG1TC Leaflet |
| 6HK1X | 183.9 kW @ 2000 r/min | EU Stage 2 | 6HK1X Leaflet |
For all other Isuzu Industrial Diesel Engines, please click on the following link to Isuzu Japan Website
Engines Plus, as the UK & Eire Distributor have the ability to package the engine to your requirements, our optional accessories include
- Engine mounted radiator kit
- Air cleaner kit
- Control panel and wiring loom
- Mounting feet
- Variable speed control
- Hydraulic pump
- Power take off arrangements
For more details, and dedicated quote to meet your power pack requirements, please contact us.
We can also offer full 3D drawing files on request
